Epoch Batteries 48V 100Ah V2 Elite Series - Heated Bluetooth Victron Comms LiFePO4 Batttery
1/7

Epoch Batteries 48V 100Ah V2 Elite Series - Heated Bluetooth Victron Comms LiFePO4 Batttery

$1,999.00

In Stock - FREE SHIPPING

Description
  • LiFePO4 Chemistry
  • Group 8D Size (20.9" x 8.7" x 12.1") L x W x H
  • 100Ah Capacity
  • 150A Max Continuous Discharge (300A 30s Discharge)
  • 150A Max Continuous Charge (300A 10s Charge)
  • IP67 Rated, Dust and WATERPROOF
  • HEATED - Internal heating for below 0C charging
  • BLUETOOTH - iOS and Android Apps
  • CANBUS Communication allows BMS to communicate directly with Victron OS
  • Mountable ON/OFF Switch
  • Mountable Battery gauge
  • Built-in Smart Battery Management System (BMS)
  • Internal fuse with current and temperature protections
  • Over charge and over discharge protection
  • Over current and short circuit protection
  • High & low temperature disconnects
  • 3500+ Cycle life & Maintenance-free
  • 11 Year Manufacturer Warranty
Specifications

Configuration
Cell Configuration: 16S1P
Chemistry: LiFePO4

Current
Ah Capacity: 100AhMax Continuous Discharge Amps: 150AMax Charge Current Amps: 150AMax Discharge Peak Current Amps: 300A @ 30secSeries | Parallel: Max (16) in Parallel, Plug & Play

Voltage
Voltage: 51.2V
Max Charge Voltage: 58.4V
Operating Voltage Range: 48.0V - 58.4V

Temperature
Charge Temp Range: -30°C (-22°F) / 55°C (131°F) (with heating)
Discharge Temp Range: -20°C (-4°F) / 55°C (131°F)
Storage Temp: -20°C (-4°F) / 45°C (113°F)

Weight & Dimensions

Weight:
97lbs

Dimensions
Length: 20.75 (inches)
Width: 8.5 (inches)
Height: 12 (inches)
