48V 100Ah (5.12kWh) V2-T Elite Series - Heated & Bluetooth & Victron Comms LiFePO4 Battery
1/3

48V 100Ah (5.12kWh) V2-T Elite Series - Heated & Bluetooth & Victron Comms LiFePO4 Battery

$2,199.00

In Stock - FREE SHIPPING

Description



  • LiFePO4 Chemistry
  • 100Ah Capacity
  • 250A EATON Class T Fuse (User Serviceable)
  • 150A Max Continuous Discharge (300A 30s Discharge)
  • 100A Max Continuous Charge (300A 10s Charge)
  • IP67 Rated, Dust and WATERPROOF
  • HEATED - Internal heating for below 0C charging
  • BLUETOOTH - iOS and Android Apps
  • VICTRON Communications with distributed charge control via DVCC
  • Parallel up to 16 batteries on 1 system
  • External Power Button & Battery Gauge INCLUDED
  • Built-in Smart Battery Management System (BMS)
  • Over charge and over discharge protection
  • Over current and short circuit protection
  • High & low temperature disconnects
  • UL60691 Certified Internal Fuse
  • UL1642, U9540A, IEC 62619:2022 Certified Cells
  • UL1973 Certified Pack
  • 3500+ Cycle life & Maintenance-free
  • 11 Year Manufacturer Warranty
Specifications

Configuration
Cell Configuration: 16S1P
Chemistry: LiFePO4

Current
Ah Capacity: 100AhMax
Continuous Discharge Amps: 150A
Max Charge Current Amps: 100A
Max Discharge Peak Current Amps: 300A @ 30secSeries | Parallel: Max (16) in Parallel, Plug & Play

Voltage
Voltage: 51.2V
Max Charge Voltage: 58.4V
Operating Voltage Range: 40.0V - 58.4V

Temperature
Charge Temp Range: -30°C (-22°F) / 55°C (131°F) (with self-heating)
Discharge Temp Range: -20°C (-4°F) / 55°C (131°F)
Storage Temp: 0°C (32°F) / 35°C (95°F)

Weight & Dimensions

Weight: 97lbs
Length: 20.75 (inches)
Width: 8.5 (inches)
Height: 12 (inches)
